Arbour Press Machine Suppliers
Workshops asking for arbour press manufacturers in India normally state the tonnage and daylight height. Civil Mechanical India is one of the suppliers in India of arbour presses from quarter ton to 4 ton, plus hydraulic and foot press types.
An arbour press is a small press for light assembly work. A manual one pushes the ram by a lever through a rack and pinion, giving a controlled force for fitting bearings, bushes and gears. Tonnage ranges here go from 1/4 ton up to about 4 ton, and the spring controlled version shows force exerted in kilograms.
A hydraulic arbour press gives higher force with less effort, and a foot press with can seaming dies handles light sheet and tin work. The listings also include round can top and bottom seaming for tins up to 350 mm diameter.
Last updated: November 2026
Spring Controlled Arbour Press
Product code: Arbour Press0002Buy Spring Controlled Arbour Press from India
Spring Controlled Arbour Press
Round Can Top And Bottom Seaming
Product code: Arbour Press0003Buy Round Can Top And Bottom Seaming from India
Round Can Top And Bottom Seaming
Hydraulic Arbour Press
Product code: CMI-NP-0376Buy Hydraulic Arbour Press from India
A hydraulic press for press fitting bearings and bushes. Features include hydraulic ram, gauge and frame.
Rack and Pinion Arbour Press
Product code: CMI-NP-0377Buy Rack and Pinion Arbour Press from India
A manual press with a rack and pinion for light press work. Features include rack and pinion, lever and table.
Arbour Press range by function
| Function | Products | What to confirm |
|---|---|---|
| Manual arbour presses | Arbour Press, Rack and Pinion Arbour Press, Spring Controlled Arbour Press | Maximum pressure in tons, ram stroke, daylight height, throat depth and lever length. |
| Hydraulic press fitting | Hydraulic Arbour Press | Capacity in tons, ram travel, pump type, working height and pressure gauge. |
| Foot and seaming presses | Foot Press, Round Can Top And Bottom Seaming | Maximum tin diameter, number of tins seamed, die set, and foot or motor drive. |
How is Arbour Press different from Power Press Suppliers?
An arbour press is a light press for assembly jobs, pressing bearings, bushes and pins, with force set by lever or hydraulic pump. A power press is a heavy production machine with a flywheel and clutch for blanking, piercing and forming sheet metal at high stroke rates. Choose an arbour press for repair and assembly work. Choose a power press for production of sheet metal parts. Arbour presses cost much less and need no special foundation.
See also: Power Press Suppliers
Full Arbour Press product list
The complete Arbour Press range (6 products), in alphabetical order:
| Arbour Press | Foot Press | Hydraulic Arbour Press |
| Rack and Pinion Arbour Press | Round Can Top And Bottom Seaming | Spring Controlled Arbour Press |
Specifications and standards
What should be checked before ordering an arbour press?
Check the capacity in tons against the force needed, daylight height between table and ram, stroke length, throat depth and table size. For hydraulic models check the pressure gauge, and for lever types the handle length and rack quality. Confirm mounting on a bench or stand.
How much tonnage do I need to press a bearing?
Required force depends on the interference fit and size. For small bearings and bushes, half to one ton is usually enough, while larger parts need two to four tons or a hydraulic model. Ask us with your part dimensions and the type of fit, and we will suggest a suitable capacity.
Who buys Arbour Press?
Garages, motor rewinding and repair shops, maintenance departments, bearing and bush fitters, tin container makers, ITIs and polytechnic workshops buy arbour presses. These presses are often ordered with bench vices, bearing pullers and drilling machines, and training workshops use them for fitting trade practice.
Related ranges
Frequently asked questions
What is a rack and pinion arbour press?
It uses a toothed rack on the ram driven by a pinion and lever. Turning the lever moves the ram precisely, giving a controlled push for assembly.
What does a spring controlled arbour press show?
A spring shows the force being applied, so the operator can press parts to a known load without overloading delicate components such as thin bushes or small bearings.
Do you supply arbour presses in India and for export?
Civil Mechanical India manufactures and supplies arbour presses in India and exports them overseas. Share the capacity, type, quantity and destination in your enquiry.
Can a seaming press close cans?
The round can top and bottom seaming machine closes tin cans up to the listed diameter, with dies for each size. State the tin size, wall thickness and number of tins per hour you need.
