Stud Type Welding Suppliers
Civil Mechanical India is one of the Stud Type Welding manufacturers in India, making equipment that welds studs and shear connectors to steel. For stud type welding suppliers in India, give us the stud diameter, material and plate thickness and we will quote the power source and gun.
Stud welding does not need drilling, tapping or a separate weld pass: a gun holds the stud against the plate, strikes an arc, and plunges the stud into the pool. Our six machines include a drawn arc stud welder for studs from about 6 mm up to 25 mm, a capacitor discharge welder for small pins on thin sheet, a portable stud gun, a shear connector unit for steel concrete composite beams, and a training station.
The key parameters are stud diameter range, weld time and current, and whether ceramic ferrules or shielding gas are used.
Last updated: November 2026
Capacitor Discharge Stud Welder
Product code: CMI-NP-0789Buy Capacitor Discharge Stud Welder from India
Capacitor Discharge Stud Welder is a stud welder using capacitor discharge for thin sheet, designed for welding small studs without burn through on thin sheets.
Drawn Arc Stud Welding Machine
Product code: CMI-NP-0790Buy Drawn Arc Stud Welding Machine from India
Drawn Arc Stud Welding Machine is a stud welder using a drawn arc with a ceramic ferrule, designed for welding threaded studs and shear connectors to steel plate.
Portable Stud Gun Welder
Product code: CMI-NP-0791Buy Portable Stud Gun Welder from India
Portable Stud Gun Welder is a portable stud gun kit, designed for welding studs on site. Key features include carry case and gun. It suits technical institutes and workshops.
Shear Connector Stud Welding Unit
Product code: CMI-NP-0792Buy Shear Connector Stud Welding Unit from India
Shear Connector Stud Welding Unit is a heavy stud welder for shear connectors, designed for welding shear studs used in composite construction. Key features include heavy and arc timer.
Stud Welding Training Station
Product code: CMI-NP-0793Buy Stud Welding Training Station from India
Stud Welding Training Station is a demonstration station for stud welding, designed for teaching stud welding. Key features include guard and table. It suits technical institutes and workshops.
Stud Type Welding range by function
| Function | Products | What to confirm |
|---|---|---|
| Structural and heavy studs | Drawn Arc Stud Welding Machine, Shear Connector Stud Welding Unit | Stud diameter range, current rating, ferrule type, gun weight and cable length |
| Thin sheet and finishing studs | Capacitor Discharge Stud Welder | Stud size range, capacitor energy, charge time and gun type |
| Site and teaching use | Portable Stud Gun Welder, Stud Welding Training Station | Kit contents, supply, safety shielding and demonstration stud sizes |
How is stud welding different from other workshop machines?
Stud welding is a joining process for fastening studs, pins and shear connectors to a surface, where the other workshop machines mostly remove metal by cutting, drilling or turning. A stud gun and power source complete a weld in under a second without pre-drilling. It is often chosen for composite construction, shipbuilding and sheet metal where drilled holes would weaken the plate.
See also: Workshop Machines
Full Stud Type Welding product list
The complete Stud Type Welding range (6 products), in alphabetical order:
| Capacitor Discharge Stud Welder | Drawn Arc Stud Welding Machine | Portable Stud Gun Welder |
| Shear Connector Stud Welding Unit | Stud Type Welding | Stud Welding Training Station |
Specifications and standards
How do drawn arc and capacitor discharge stud welding compare?
Drawn arc welds larger studs, typically 6 mm and above, with a ferrule or gas shield and gives deep penetration for structural work. Capacitor discharge welds small studs on thin or coated sheet with almost no heat marking on the other side. Choose by stud size, plate thickness and whether the reverse surface must stay clean.
What should I confirm before ordering a stud welder?
State stud diameter and length, stud and plate material, and the production rate per hour. Confirm the power source current range, the cable length to the gun, the supply (415 V three phase for drawn arc) and whether ferrules and chucks are included. Ask for test bend or hammer tests on sample studs.
Who buys Stud Type Welding?
Steel structure and bridge contractors, shipyards, boiler and panel makers, sheet metal shops, engineering colleges and welding training institutes buy stud welding equipment. A site team normally orders the shear connector unit with a generator-friendly power source, while a college lab takes the training station. It joins other welding equipment such as arc welders in a fabrication order.
Related ranges
Frequently asked questions
What are shear connector studs used for?
Shear connectors are welded to steel beams so the concrete slab and the beam act together as a composite section. They are placed through the metal deck on site. The welder must deliver enough current for the stud diameter.
Why is a ceramic ferrule used in drawn arc stud welding?
The ferrule contains the molten pool, shields it from air and shapes the weld fillet. It is broken off after welding. Ferrules must be dry and sized to the stud.
Can stud welding be done on coated or thin sheet?
Capacitor discharge welding is meant for thin sheet and surface-coated materials since the weld time is milliseconds. Drawn arc needs thicker plate to avoid burn through. Plate thickness should be at least about one third of the stud diameter.
Do you export stud welding machines?
Yes, we ship from India to overseas contractors as well as domestic ones. Power sources and guns are crated with cables and chucks. Provide quantity and destination for packing details.
