Slab Trolley with Rails
Product code: Slab Trolley0001Buy Slab Trolley with Rails from India
Slab Trolley with Rails
Civil Mechanical India is one of the Slab Trolley with Rails manufacturers in India, building flat-bed and rail guided trolleys for moving heavy precast pieces around a casting yard. When you look for slab trolley with rails suppliers in India, give us the slab size, weight and track gauge and we will quote the frame and wheel set.
A slab trolley is a low welded steel platform on wheels, sometimes riding on a fixed rail so it can only travel along the yard line. Our six items cover a standard railed trolley, a motorised slab transfer trolley, a rail mounted transfer unit, a casting table trolley, a rubber wheel version for finished floors and a tilting trolley that lets a slab be tipped for demoulding.
The things that set a trolley apart are its rated load, platform size, wheel type and whether it is hand pushed or driven. Rail guided versions keep a slab steady over long runs, and rubber wheels avoid damaging a polished floor.
Last updated: November 2026
Slab Trolley with Rails
Motorised Slab Transfer Trolley is a motor driven rail trolley with a pendant control, designed for remote powered movement of heavy slabs in a testing hall.
Rail Mounted Slab Transfer Trolley is a heavy trolley with flanged wheels that runs on floor rails, designed for transferring heavy slab specimens between curing and testing stations.
Slab Casting Table Trolley is a casting table mounted on a rail trolley, designed for casting and carrying concrete slab test panels. Key features include flat steel table top and rail wheels.
Slab Trolley with Rubber Wheels is a hand pushed steel trolley on four rubber wheels with a flat deck, designed for moving concrete slabs, stone slabs and heavy panels within a laboratory.
Tilting Slab Trolley is a trolley with a hinged deck that can be tilted, designed for loading and unloading slabs and sheets by tilting the deck.
| Function | Products | What to confirm |
|---|---|---|
| Hand moved trolleys | Slab Trolley with Rubber Wheels, Tilting Slab Trolley | Load rating, deck size, wheel type and tilt angle and lock |
| Rail mounted transfer | Rail Mounted Slab Transfer Trolley, Slab Trolley with Rails, Slab Casting Table Trolley | Rail gauge, flanged wheel size, deck length, load and casting table dimensions |
| Powered transfer | Motorised Slab Transfer Trolley | Motor kW, pendant control, travel speed, power feed and limit stops |
A 10/7 cft concrete mixer produces fresh concrete in a drum, so it is a batching and mixing machine with an engine or motor. A slab trolley handles the product after casting, carrying the hardened or green slab to storage. In a yard, the mixer is at the start of the line and the trolley at the end. They are rated differently, mixers by drum capacity and trolleys by load in kilograms or tonnes.
See also: 10 7 cft Concrete Suppliers
The complete Slab Trolley with Rails range (6 products), in alphabetical order:
| Motorised Slab Transfer Trolley | Rail Mounted Slab Transfer Trolley | Slab Casting Table Trolley |
| Slab Trolley with Rails | Slab Trolley with Rubber Wheels | Tilting Slab Trolley |
Work out the heaviest slab plus any mould or pallet that rides with it, and add a margin. A 1 m by 1 m slab 100 mm thick weighs about 250 kg, so standard trolleys are usually rated in the 500 kg to 2 tonne range. Check the axle, wheel bearing and frame section, not only the quoted figure.
Railed trolleys suit a fixed casting line with repeating travel and are the most stable. Rubber wheel trolleys move freely on finished floors and need no track. A motorised unit saves labour on long runs or heavy slabs, but needs a power point or battery. Choose by distance, slab weight and yard layout.
Precast concrete yards, paver block and tile makers, construction contractors, civil engineering colleges with a concrete lab and public works training centres buy slab trolleys. In a casting setup the trolley is ordered along with vibrating tables, curing tanks and moulds, so slabs are never lifted by hand. Larger buyers specify rail gauge and platform size to fit existing sheds.
Track gauge depends on trolley width, and common yard gauges run from about 600 mm to over 1 m. The rail should be level and bolted to the floor. Give your slab width and run length and we will suggest gauge and platform size.
A tilting trolley lets the platform be raised on one side so a cast slab or panel can be slid off or stood upright for demoulding. It reduces manual lifting and the risk of cracking green concrete. It is suited to wall panels and large tiles.
Yes, steel wheels suit rails, and rubber or polyurethane wheels suit smooth floors. For uneven yards, larger pneumatic wheels are an option on hand pushed models. State the surface when ordering.
Yes, we ship from India to overseas precast and construction customers. Trolleys are shipped on a pallet or as a knock-down frame with wheels packed separately. Send the quantity and destination and we will advise the packing.
Civil Mechanical India is an established manufacturer and supplier for tender requirements from India, handling civil laboratory and industrial testing tenders and bulk and OEM orders for mechanical engineering and testing laboratory equipment. On receipt of your tender specifications, we will submit a complete quotation for Slab Trolley with Rails.
Send us your equipment list or tender specification. We quote against IS, BS, EN, ASTM and AASHTO standards and ship to 90+ countries.
