Electric Operated Spur Gear Chain Pulley Block
Product code: Electric Operated0001Buy Electric Operated Spur Gear Chain Pulley Block from India
Electric Operated Spur Gear Chain Pulley Block
Electric chain pulley block manufacturers in India supply hoists for workshops that need to lift engines, dies and machinery. Civil Mechanical India is among the suppliers in India with capacities from 250 kg to 2 tonne, including trolley mounted versions.
An electric chain hoist uses a motor, spur gear drive and load chain to lift and lower with push button control. The 250 kg single phase hoist is for light loads in labs and small workshops. The 500 kg hoist covers general workshop lifting.
The 1 tonne and 2 tonne hoists suit engine lifting and heavy machinery. The version with a motorised trolley travels along an I beam, so loads can be moved horizontally as well as lifted, which is useful in assembly bays and production lines.
Last updated: November 2026
Electric Operated Spur Gear Chain Pulley Block
One tonne hoist for workshop use with a robust gear box. Used in college labs to lift engines and heavy parts. Main ratings: capacity 1000 kg, lift height 3 m, motor 1 HP, 415 V AC.
Two tonne hoist for lifting heavy machinery. Used in heavy workshops. Main ratings: capacity 2000 kg, lift height 3 m, motor 2 HP, 415 V AC.
Electric chain hoist with spur gear drive and push button control for lifting loads. Used in workshops to lift machine parts. Main ratings: capacity 500 kg, lift height 3 m, motor 0.5 HP, 415 V AC.
Small single phase hoist for light loads in labs and workshops. Used for lifting small machines. Main ratings: capacity 250 kg, lift 3 m, motor 0.25 HP, 230 V AC.
Hoist with motorised trolley for travel along an I beam. Used in assembly bays for moving loads horizontally. Main ratings: capacity 1000 kg, lift 3 m, trolley speed 10 m/min.
| Function | Products | What to confirm |
|---|---|---|
| Light loads | Electric Chain Hoist Single Phase 250 kg, Electric Chain Hoist 500 kg | Rated load, lift height, lifting speed, supply voltage and push button pendant length. |
| Heavy lifting | Electric Chain Hoist 1 Tonne, Electric Chain Hoist 2 Tonne | Rated capacity, duty class, chain size, three phase supply and limit switch. |
| Lifting with travel | Electric Chain Hoist With Trolley | I beam flange width range, trolley speed, beam length and end stops. |
Most Workshop Machines cut, form or shape material at a bench or floor station. An electric chain pulley block is lifting equipment, not a machining tool, so it is chosen by rated load, lift height, duty cycle and the structure it hangs from. A beam or gantry capable of carrying the hoist load is part of the buying decision, and safe working load markings and inspection routines apply.
See also: Workshop Machines
The complete Electric Chain Pulley Block range (6 products), in alphabetical order:
Confirm the heaviest load including slings, the lift height needed, supply (230 V single phase or 415 V three phase), lifting speed, duty class and chain length. Check upper and lower limit switches, overload protection, hook latches and the pendant. Verify the beam or support structure rating before installation.
Choose a trolley when loads must move along a beam, such as in an assembly bay or between machines. A fixed suspension hoist lifts only vertically. Match the trolley to the I beam flange width and plan end stops on the beam.
Engineering college workshops, automobile and mechanical labs, fabrication units, assembly lines, maintenance sections and engine repair shops buy electric chain hoists. They are usually part of a lifting and handling package with beams, slings and load test certificates. Auto service sections use them for engine removal.
Provide the load, lift height and supply voltage. Please share the load, lift height and supply voltage, and we will confirm the model, chain length and packing for your location or port.
Lifting equipment is normally load tested before use, and local rules may require periodic inspection. Raise this at quotation stage if documents are needed. Lifting equipment is normally load tested and inspected before use, and local rules may need periodic checks. Raise it early so that documentation can be arranged with the quote.
The beam must be strong enough for the hoist and load, and the trolley must match the flange. A structural engineer should confirm. The beam must carry the hoist and load with a safety margin, and the trolley wheels must match the flange width. Ask a structural engineer to confirm the support before installation.
Check and lubricate the chain, test limit switches and the brake regularly, and replace worn hooks or chain links. Check and lubricate the chain, test limit switches and the brake regularly, and replace worn hooks or chain links promptly. Keep a log of inspections for the lab or workshop.
