Chain Mortiser Economy Model
Product code: Chain Mortiser0001Buy Chain Mortiser Economy Model from India
Chain Mortiser Economy Model
Chain mortiser economy model manufacturers in India supply the entry level machine that carpentry shops use for door and window joinery. Civil Mechanical India is among the suppliers in India that offer five light duty variants, each solving a different handling problem.
The economy chain mortiser is a light duty machine with a single phase motor and a chain and guide bar that plunges into the timber. It costs less than production machines and is well suited to training and low volume joinery.
The variants differ in work handling. The stand model puts the machine at a comfortable height, the foot pedal clamp frees both hands, the table stop and sliding fence make repeat mortises equal in depth, and the tilting table allows angled mortises for chairs and frames.
Last updated: November 2026
Chain Mortiser Economy Model
Floor standing economy chain mortiser mounted on a pedestal stand at comfortable working height. Used in school and ITI carpentry shops for door and window frame joints.
Chain mortiser with a foot pedal operated work clamp, leaving both hands free to position timber. Used in furniture and joinery training shops for repetitive mortising.
Light duty chain mortiser using a cutting chain on a guide bar to cut rectangular mortises in timber. Used in carpentry workshops for door, window frame and furniture joinery training.
Entry level chain mortiser with a graduated depth stop and sliding fence for repeat mortises. Used by trainees to cut accurate joints in doors and frames.
Chain mortiser whose table tilts left and right for angled mortises used in chair and frame work. Used in carpentry training to explain angular joinery.
| Function | Products | What to confirm |
|---|---|---|
| Basic economy machines | Economy Chain Mortiser With Single Phase Motor, Economy Chain Mortiser Stand Model | Motor power in kW or HP, chain pitch, maximum mortise depth and width, and stand height. |
| Work holding and repeat cuts | Economy Chain Mortiser With Foot Pedal Clamp, Economy Chain Mortiser With Table Stop | Clamp force, pedal travel, depth stop scale readings and fence length. |
| Angled mortises | Economy Chain Mortiser With Tilting Table | Tilt range left and right, table size, locking system and chain guard. |
The economy chain mortiser is built for lighter timber, lower daily running hours and tighter budgets, normally with a single phase motor. The heavy duty chain mortiser uses a larger motor, stronger column and options such as hydraulic feed and pneumatic clamping, meant for hardwood beams and production. Choose economy for training and small furniture work, heavy duty for daily production on dense timber.
See also: Chain Mortiser Heavy Duty Suppliers
The complete Chain Mortiser Economy Model range (6 products), in alphabetical order:
Check the maximum mortise depth and width, the chain pitch, motor power with 230 V single phase supply, and table size. Confirm how the timber is clamped, the guard design around the chain, and the availability and price of replacement chains, guide bars and sprockets, since these wear out first.
A stand model with a foot pedal clamp is convenient and safe because the operator keeps both hands free. If students learn chair or frame joints, a tilting table is useful. A table stop helps with repeat mortises for door frames.
ITI carpentry trades, polytechnic wood workshops, school vocational rooms, small furniture and door frame makers and carpentry training centres buy economy chain mortisers. A full wood workshop order combines them with bandsaws, planers, sanders and a dust collector. Institutes often equip a whole carpentry lab with four or six of them.
Yes, Civil Mechanical India manufactures and supplies these machines in India and for export. Tell us your voltage and quantity and we will confirm the motor and packing.
Chains dull with use, especially in hardwood or with resin. Sharpen or replace when the cut becomes rough or the motor strains. Keep a few spare chains and guide bars in stock.
Each model has a maximum mortise width and depth, which depends on the chain and guide bar. Give us your joint dimensions and we will advise a suitable model.
Economy models run on single phase supply, which suits schools and small shops. Heavy duty versions with larger motors usually need three phase. Larger heavy duty mortisers need three phase, so check your workshop supply before ordering.
