Ram Turret Universal Milling Machine All Auto Feed
| Product code | Milling0005 |
| Categories | Milling Machines |
| Standards | Manufactured to IS / BS / EN / ASTM / AASHTO as applicable |
| Supply | India and export — 90+ countries |
- Description
Ram Turret Universal Milling Machine All Auto Feed
Specification
Ram Turret Universal Milling Machine All Auto Feed
| Working Table | 1250 x 275 |
| T-Slot No & Size | 3x 13 |
| Distance between T Slots | 65 |
| Swivel of Table (for UM Models) | 45° |
| Swivel of Table (for VM Models) | Fixed |
| SPINDLE | |
| Arbour Diameter (only for UM Models) | 25.4 |
| No & Range of Speeds | 9 (50 to 950) |
| Taper of Spindle | ISO-40 |
| Dist. from Centre of Spindle to Table Top (Min/Max. for VM Models) | 15-425 |
| Dist. from Centre of Spindle to Column (For VM Models) | 325 |
| VERTICAL HEAD | |
| Swing of Vertical Head to either side (For VM Models) | 90° |
| Manual Quill Movement | 65 |
| FEEDS | |
| X - Longitudinal | 625 |
| Y - Cross | 200 |
| Z - Vertical | 405 |
| No. & RANGE OF FEEDS (Feeds per min. / mm) | |
| X - Longitudinal | 6 (11 to 75) |
| Y - Cross | 6 (11 to 91) |
| Z - Vertical | 6 (2 to 14) |
| NO. & RANGE OF RAPID FEEDS | |
| X - Longitudinal | 1 (384) |
| Y - Cross | 1 (470) |
| Z - Vertical | 1 (76) |
| ELECTRICALS | |
| Main Drive (Spindle) Motor (1400 RPM) | 2 HP |
| Feeds Drive Motor (960 RPM) | 2 HP |
| Coolant Motor (2800 RPM) | 0.1 HP |
| VERTICAL ATTACHMENT ON RAM | |
| Cross (Min. / Max.) | 135-425 |
| Vertical (Min. / Max.) | 100-500 |
| Speeds for Vertical Head (Ram Type) | 6 (95 - 550) |
| Quill Movement (Manual) | 50 |
| Electric Drive Motor | 1 HP |
| WEIGHT | |
| Net | 2200 Kg. |
| Gross | 2500 Kg |
