Hydraulic Cylindrical Grinding
| Product code | GMS0005 |
| Categories | Grinding Machines Manufacturers Suppliers |
| Standards | Manufactured to IS / BS / EN / ASTM / AASHTO as applicable |
| Supply | India and export — 90+ countries |
- Description
Hydraulic Cylindrical Grinding
Specification
| Max.Grinding Length | 300 mm | 450/600/1000 |
| Max. Height of Center | 100 mm | 125 mm |
| Range of Table feed per min | 0.05 / 1.5 | 0.05 / 1.5 |
| Max. Table Swivel | 7+2 =9 | 6+2=8 |
| Hydraulic Power Motor | 1 H.P./0.75KW | 1 HP./0.75 KW |
| Work Head Swivel on | 45 towards wheel head | |
| Work Head Speed Range | (3) 75,150, 350 | (3) 60,120,250 |
| Work Head Motor | 0.5 HP/ 0.37 KW | 0.5 HP/0.37 KW |
| Size of Grinding Wheel | 350x25x 127 | 350x38x 127 |
| Min. Dia.of Worn Out Wheel | 250mm | 250mm |
| R.P.M. of Grinding Wheel | 1900 | 1900/2100 |
| Wheel Head Motor | 2 HP/1.5. KW | 3 HP/2.25. KW |
