Construction Lab Equipment Manufacturers and Suppliers in India

Construction Equipment Lab

Quick answer: Construction lab equipment here is a compact group for mixing, flexural testing and handling in civil labs: a laboratory pan mixer, a laboratory-type concrete mixer, a motorised flexural testing machine and a 1000 kg tipper. Civil Mechanical India manufactures and supplies these for college labs and site laboratories.

Small civil labs often need a few heavy machines before anything else, a mixer to make trial batches and a flexural frame to break beams. Civil Mechanical India builds these as construction lab equipment manufacturers in India, and the same sets are available from us as suppliers in India for polytechnics and site testing rooms.

This range is short on purpose. The laboratory pan mixer uses rotating paddles in a fixed pan, which gives thorough mixing of small batches of concrete, mortar and cement samples and suits trial mixes and test specimens. The laboratory-type concrete mixer is offered in two versions, giving a choice for batch size and mobility.

The flexural testing machine is a motorised load frame whose lower platen carries two rollers at an adjustable spacing, used to find the modulus of rupture of concrete beams and similar members. A Hycon 1000T tipper rated at 1000 kg handles movement of aggregates and mixed concrete around the lab yard. Most buyers add these to moulds, a compression machine and curing tanks.

Last updated: November 2026

Laboratory Pan Mixer

Product code: CMI-NP-0256
Buy Laboratory Pan Mixer from India

A pan type concrete mixer with rotating paddles for thorough mixing of concrete, mortar and cement samples in the lab. Used for preparing trial mixes and test specimens.

Construction Lab Equipment range by function

FunctionProductsWhat to confirm
Laboratory mixingLaboratory Pan Mixer, Concrete Mixer (Laboratory Type)Batch capacity in litres, pan or drum design, motor rating and voltage, discharge method and whether paddles and liners are replaceable.
Flexural strengthFlexural Testing MachineMaximum load, roller spacing, specimen size (beam 100 x 100 x 500 mm or 150 x 150 x 700 mm), loading rate control and the standard followed.
Material handlingHycon 1000T TipperLoad capacity of 1000 kg, tipping mechanism, wheel type, frame strength and finish for outdoor use.

How is this different from concrete testing equipment?

This group is about machinery for making and moving material: mixers, a beam-bending frame and a tipper. The concrete testing range is mostly instruments and tools, such as slump cones, moulds, vibrating tables and permeability cells. A trial mix is made in a mixer from this page, then workability and moulds from the concrete range are used on that batch.

See also: Concrete Testing Lab Equipment

Full Construction Lab Equipment product list

The complete Construction Lab Equipment range (4 products), in alphabetical order:

Specifications and standards

How do I size a laboratory pan mixer?

Choose the pan for the largest batch you will cast, remembering that mixers should be filled to about 60 percent of rated capacity. A 40 to 60 litre pan covers eight to ten 150 mm cubes. Check motor power, three-phase or single-phase supply, the pan and paddle material and whether the discharge is manual or tilting.

What should be confirmed for a flexural testing machine?

Check the maximum load, the roller span adjustment for 100 x 100 x 500 mm and 150 x 150 x 700 mm beams, and the loading rate control. IS 516 describes two-point loading for concrete beams, so ask for third-point loading arrangement with the machine. A digital load readout and a safety guard are worth including.

Is the 1000 kg tipper suitable for laboratory use?

It suits labs with a yard, moving aggregate bins and mixed concrete in barrow-style loads over short distances. Check the tipping mechanism, wheel type and frame finish for outdoor use, and make sure the doorway or ramp can take its width when loaded.

Who buys Construction Lab Equipment?

Polytechnic and engineering college civil departments buy the mixers and flexural machine to equip a concrete lab, usually together with moulds and a compression tester. Small contractors and site laboratories use the pan mixer for trial mixes before a pour, and municipal labs use the flexural machine for paving blocks and slabs. The tipper is bought by workshops and sites that move aggregate in bulk.

Related ranges

Frequently asked questions

Can the pan mixer also mix mortar and cement paste?

Its rotating paddles suit concrete, mortar and cement samples, though for IS 4031 strength cubes a dedicated standard mortar mixer is preferable. Tell us which standards your mortar tests follow.

What specimens can the flexural machine test?

Standard concrete beams are the main use. With suitable rollers it also tests small slabs and paving elements. Confirm the specimen size and span before ordering so the roller fixture is correct.

What power supply do the mixers need?

Laboratory mixers run on 230 V single-phase or 415 V three-phase depending on motor size. State your site supply so we can fit the right motor and starter.

Do you supply these items outside India?

Yes, export supply is possible for overseas colleges and contractors. Give the destination country and mains voltage and we will quote with suitable motors, starters and sea-freight packing.

What accessories go with the flexural machine?

A pair of roller supports, a loading roller set, a load readout or gauge, and ideally a beam mould for casting test specimens. Request them in the same quote to keep spans compatible.

Tender enquiries

Request a tender quotation

Civil Mechanical India is one of the leading manufacturers and suppliers in India for tender requirements, covering civil laboratory and industrial testing tenders and the bulk and OEM supply of mechanical engineering and testing laboratory equipment. Kindly share your tender specifications and we shall submit a complete quotation for Construction Lab Equipment.

  • Civil laboratory & industrial testing tenders
  • Mechanical engineering & testing lab equipment
  • Bulk and OEM supply
Send Tender Specifications Quotation prepared against your tender specifications
Get a quotation

Planning a civil engineering laboratory or replying to a tender?

Send us your equipment list or tender specification. We quote against IS, BS, EN, ASTM and AASHTO standards and ship to 90+ countries.
