Medium Duty Hardened Bed Under Motor Norton Gear Type Lathe Machine 550M

Medium Duty Hardened Bed Under Motor Norton Gear Type Lathe Machine 550M

Specification

Medium Duty Hardened Bed Under Motor Norton Gear Type Lathe Machine 550M

STANDARD ACCESSORIES :
Two dead Centres, Centre Sleeves, Square Tool Post, Tool Post Key, Gear Set for MM & Inch Thread, Carrier Plate, Motor Pulley, Thread Chart, Suitable Electric Motor, Dog Chuck with Flangue, R/F Switch, V Belt.

OPTIONAL ACCESSORIES :
Quick change Norton Gear Box, Rear Tool Post, Taper Turning attachment, Coolant unit with Assembly, Machine Lamp, 3 Jaw True Chuck, Chuck Flange, Face Plate, Steady Rest & Follow Rest, Revolving Centre.

Size	4'.6" / 6'
	Inch.
Length of Bed	54"/72"
Width of Bed	10"/10"
Height of Centre	8"/8"
Admit between Centres	23"/40"
Dia. of Hole through Spindle	1-5/8"
Swing over Bed (Max.)	16"
Swing in Gap (Max.)	23"
Swing over cross slide	10"
Tail Stock Spindle Travel	6"
Spindle Speeds No.	8
Range	45-800 RPM
Spindle Morse Taper	MT-4
Lead Screw Dia.	1.1/8" x 4 T. P. I.
Threading Range	0.5 to 40 T. P. I. & 0.5 to 8 mm pitch
or
Dia Threading Range	1.1/8" x 6 T. P. I. 1 to 45 T. P. I. & 0.5 to 6 mm pitch
Required H.P.	2 H.P.
