Turret Milling Machine

Turret Milling Machine

Code: Gear Drive0002

Turret Milling Machine.

Table Size 230x1067mm 254x1270/1370mm 254x1270/1370mm 254x1270/1370mm
Table Load 250Kgs 300Kgs 300Kgs 350Kgs
X Axis Travel 610mm 780mm/880mm 780mm/880mm 780mm/860mm
Y Axis Travel 350mm 395mm 395mm 420mm
Z Axis Travel 380mm 380mm 380mm 380mm
Motor Output 3.0HP 3.0HP 3.0HP 5.0HP
Head Structure Belt Driven Head Belt Driven Head Belt Driven Head Belt Driven Head
Taper of Spindle Bore R8 or NT-30 R8 or NT-30 R8 or NT-30 NT-40
No. of Spindle Speed 16speeds 16speeds 16speeds 16speeds
Range of Spindle Speed 80-5400rpm 80-5400rpm 80-5400rpm 80-5400rpm
Spindle Rotation Angle 45Degree 45Degree 45Degree 45Degree
Spindle feed Rate 0.04, 0.08, 0.15mm/r 0.04, 0.08, 0.15mm/r 0.04, 0.08, 0.15mm/r 0.04, 0.08, 0.15mm/r
Ram Travel 305mm 510mm 580mm 580mm
Ram Rotation Angle 360Degree 360Degree 360Degree 360Degree
Dimensions(LxWxH) 1500x1530x2100mm 1700x1550x2100mm 1700x1550x2100mm 1700x1550x2350
