Steam Power Plan

Steam Power Plan

Specification

Steam Power Plan

1. Laboratory-sized steam power plant
2. Oil-fired steam generator with electric superheater
3. Single-stage axial turbine with curtis wheel, vacuum or exhaust operation
4. Dc generator as turbine load
5. Water-cooled condenser
6. Feedwater treatmen

Technical Data

1. Steam generator
2. Steam output: 200kg/h at 11bar
3. Max. Fuel consumption: 12L/h
4. Heat-up time: 8min
5. Max. pressure: 13bar

Superheater

1. Power: 7kw
2. Single-Stage Axial Turbine With Curtis Wheel And Hydraulic Speed Regulator
3. Power: max. 1,5kW at 3000min-1

Water-Cooled Condenser

1. Cooling capacity: 98kw
2. Transfer surface: 2,5m²

Measuring Ranges

1. Temperature: 9x 0...400°c, 2x 0...100°c
2. Cooling water flow rate: 0...167l/min
3. Pressure: 3x 0...16bar, 1x -1...1bar
4. Torque: 0...20nm
5. Speed: 0...4000min-1
